Making selections in the following sections may change the final product price.

Hub Face (required)

The hub face is the measurement of the flat surface where the wheel mounts onto your hub to the exact same spot across the axle.

Specify Your Hub Face (Between 45" - 95", in 1" increments)(We only stock odd lengths ex: 61")

Trailer Hub Bolt Pattern (required)

4 bolt - 4" bolt circle contains Hubs, Seals, Bearings, and Caps

4 bolt - 4" bolt circle contains Hubs, Seals, Timken Bearings, and Caps [Add $44.00]

5 bolt - 4.5" bolt circle contains Hubs, Seals, Bearings, and Caps

5 bolt - 4.5" bolt circle contains Hubs, Seals, Timken Bearings, and Caps [Add $44.00]

Summary

• 4 bolt - 4" bolt circle contains Hubs, Seals, Bearings, and Caps

Base Price: $199.99

Customized Price: $199.99

Quantity Add to Cart

Description

Trailer Axle: 1 3/4" x 3/16" nominal wall round tubing available in straight only. Idler Hubs Available: 4-4", or 5-4.5". Lubrication: Grease. Spindle: Type BT9 with an inner and outer journal dimension of 1 1/16". Trailer axle price does not include springs, hangers, or U-bolts. Trailer axles are available in different lengths or hub faces. Maximum Overhang = 15" Minimum Overhang = 10" Overhang is the difference between the spring center and the hub face. Exceeding the maximum overhang will result in reduced axle capacity. Minimum Overhang dimensions are based on zero offset wheels and physical clearances; and are determined by suspension type, wheel and tire combination.  Axles are straight axles, not cambered.  Coated with standard black paint.  Axle seats and lug nuts come loose with axle.  Trailer axle assembly contains trailer axle beam with pressed in spindles, hubs (races pressed), bearings, grease cap, and grease seal, axle seats, and lug nuts (some assembly required)
